Universal Fibre Cable Pole Bracket UPC
The UPC universal pole bracket carries tension and suspension clamps for ADSS and figure-8 optical cables. It accommodates different routing directions and angles in outdoor telecommunications installations.
Features
- Single-piece body with at least three cable attachment points
- Suitable for both anchoring and suspension duties
- Mounts with stainless steel banding or a pole bolt and nut
- High-strength, corrosion-resistant aluminium construction
- Pole-mounted tension application for 70–200 m spans
- Specified minimum breaking load: 15 kN
- Economical, lightweight design
Application
The one-piece bracket is produced from high-strength die-cast aluminium. Its low mass and mechanical strength suit long-term use under the specified loads. Install it on a pole using a bolt and nut or stainless steel banding, and select compatible ADSS or figure-8 tension or suspension clamps for the cable route. Carton packing is used, with pallet packing available.
| Product code | Weight, kg |
| UPC | 0.2 |
Mechanical and environmental evaluation should follow the applicable product specification and installation requirements. Product-specific test reports should be checked before use.
